Siemens SINAMICS S120 Combi - Technical Data

Additional system components
9.2 DRIVE-CLiQ Hub Module DMC20
SINAMICS S120 Combi
216 Manual, 11/2017, 6SL3097-4AV00-0BP7
9.2.7
Technical data
Table 9- 19 Technical data of the DMC20
6SL3055-0AA00-6AA1
Unit
Value
Electronics power supply
Voltage
Current (without DRIVE-CLiQ node)
Maximum cable length
V
DC
A
DC
m
24 V DC (20.4 ... 28.8)
0.15
30
PE/ground connection
At the housing with M4 screw
Ventilation clearances, above/below
mm
50
Weight
kg
0.36
