Siemens SINAMICS S120 Combi User Manual

S120 Combi Power Modules
4.3 Interface description
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
77
4.3.7
X200-X205 DRIVE-CLiQ interfaces
Table 4- 12 X200-X205 DRIVE-CLiQ interfaces
PIN
Signal name
Technical data
1
TXP
Transmit data +
2 TXN Transmit data -
3
RXP
Receive data +
4
NC
5
NC
6
RXN
Receive data -
7
NC
8
NC
A
+ (24 V)
Power supply
B
M (0 V)
Electronics ground
Connector
type
DRIVE-CLiQ socket
The blanking covers for the DRIVE
-CLiQ interfaces are included in the scope of delivery.
Blanking covers (50 x) Article number: 6SL3066-4CA00-0AA0
Note
DRIVE-CLiQ interface X204
For 3 axes Power Modules of the S120 Combi, there is no DRIVE
-CLiQ interface X204.
