12.8 Note on control cabinet cooling
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
299
12.8.3
Dimensioning Climate Control Equipment
Cabinet manufacturers provide calculation programs for selecting climate control equipment.
It is always necessary to know the power loss of the components and equipment installed in
the cabinet.
The physical relationship is shown in the following example.
Calculating the thermal power to be dissipated: q = Q - k * A * ΔT
with
q = thermal power that has to be dissipated using a cooling unit [W]
Q = power loss [W]
∆T = difference between the room temperature and the temperature inside the cabinet [K]
k = heat transfer coefficient, e.g. sheet-steel, painted 5.5 [W/(m
2
* K)]
A = free-standing cabinet surface area [m
2
]
Table 12- 16 Example, calculating the power loss of a drive configuration
Component
Number
Total power loss [W]
(including electronic losses)
Total power loss [W]
SINUMERIK 828D
1
28
28
Line filter 1 16 16
Line reactor
1
98
98
S120 Combi 3 axes Power
Module 20 kW
1 634 634
Motor Module 9 A
1
100.4
100.4
Motor Module 18 A
1
185.4
185.4
SMC
2
10
20
SITOP 20
1
53
53
Line contactor
1
12
12
Total:
1146.8
Assumption:
free-standing control cabinet surface A = 5 m
2
difference between the room temperature and the temperature inside the control cabinet ∆T
= 10 K
q = 1146.8 W - 5.5 W / (m
2
K) * 5 m
2
* 10 K = 871.8 W
