Siemens SINAMICS S120 Combi User Manual

Motor Modules Booksize Compact as expansion axes
6.8 Technical data
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
147
6.8.1
Characteristics
Rated duty cycles Motor Modules Booksize Compact
Figure 6-8 Duty cycle with initial load
Figure 6-9 Duty cycle without initial load
Figure 6-10 S6 duty cycle with initial load with a duty cycle duration of 600 s
Figure 6-11 S6 duty cycle with initial load with a duty cycle duration of 60 s
