Page #45 background imageLoading...
Page #45 background image
Line-side power components
3.7 Line reactors
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
45
3.7.3.2
Line/load connection
Table 3- 4 Connection of line reactors
Article number
6SL3100-0EE21-6AA0
6SL3100-0EE22-0AA0
Power [kW]
16
20
Line connection 1U1, 1V1, 1W1
Type: Screw terminal 7 (Page 288)
Type: Screw terminal 7 (Page 288)
Load connection 1U2, 1V2, 1W2
Type: Screw terminal 7 (Page 288)
Type: Screw terminal 7 (Page 288)
Protective conductor connection Type: M6 bolt
Tightening torque: 6 Nm
M6 bolt
Tightening torque: 6 Nm
Note
A 6SL3111
-4VE21-0EA1 Power Module (10 kW) must be combined with a 6SL3100-0EE21-
6AA0 line reactor.
