Cabinet design and EMC
12.5 Connection system
SINAMICS S120 Combi
290 Manual, 11/2017, 6SL3097-4AV00-0BP7
12.5.6
Cable lugs
Figure 12-3 Dimension drawing of cable lugs
Table 12- 13 Dimensions of cable lugs
Screw/bolt
Cable cross-section
[mm
2
]
a
[mm]
c
[mm]
d
1
[mm]
d
2
[mm]
d
3
[mm]
l
[mm]
r
[mm]
s
[mm]
M5
6
6
6
3.6
5.3
10
15
6.5
1
