Cabinet design and EMC
12.8 Note on control cabinet cooling
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
301
12.8.4.3
Power losses for S120 Combi Power Modules
Power losses in rated operation
The following table provides an overview of the internal and external losses of the S120
Combi Power Modules for rated operation.
Table 12- 18 Overview of power losses in rated operation for S120 Combi Power Modules
Unit
Internal
power loss
External power
loss
Total
power loss
1)
S120 Combi 3 axes Power Module
16 kW / 18 A / 5 A / 5 A
W
81
344
425
16 kW / 24 A / 9 A / 9 A
W
91
446
537
20 kW / 30 A / 9 A / 9 A W 102 532 634
S120 Combi 4 axes Power Module
10 kW / 24 A / 12 A / 12 A /
12 A
W 115 655 770
16 kW / 18 A / 9 A / 5 A / 5 A
W
87
405
492
16 kW / 24 A / 9 A / 9 A / 9 A
W
100
507
607
20 kW / 30 A / 12 A / 9 A /
9 A
W 113 620 733
1)
The external fan unit has been taken into account in the specified power losses
12.8.4.4
Power loss for line filters and line reactors
Table 12- 19 Overview of power loss during rated operation for line filters and line reactors
Unit
Power loss
Line filter
10 kW
W
12
16 kW
W
15
20 kW
W
16
Line reactors
10 kW
W
55
16 kW
W
75
20 kW
W
98
