Cabinet design and EMC
12.5 Connection system
SINAMICS S120 Combi
284 Manual, 11/2017, 6SL3097-4AV00-0BP7
DRIVE-CLiQ signal cable
MOTION-CONNECT 500
MOTION-CONNECT 800PLUS
Oil resistance
EN 60811-2-1
(mineral oil only)
EN 60811-2-1
Protective jacket
PVC PUR, HD22.10 S2
(VDE 0282, Part 10)
Flame retardant
EN 60332-1-1 to 1-3
EN 60332-1-1 to 1-3
1)
The file number is printed on the cable jacket.
12.5.2
Power cables for motors
12.5.2.1
Approved power cables
Note
Only MOTION
-CONNECT 500 and MOTION-CONNECT 800 power cables are permissible
for the S120 Combi.
Table 12- 7 Approved power cables for motors connected to the S120 Combi - prefabricated
Motor
Article number
6FXx002-
Description
D
max
6FX5 6FX8
1PH8 with terminal box
5CE02
Power cable 1PH808 4 x 2.5
10.0
12.1
1PH8 with terminal box
5CE04
Power cable 1PH810 4 x 4
11.4
13.2
1PH8 with terminal box
5CE06
Power cable 1PH813 4 x 6
13.6
16.0
1FT7/1FK7 with quick release 5CF10 Power cable 4 x 1.5 GR.1 SC 8.4 10.4
5DF10
Power cable 4 x 1.5 + 2 x 1.5 GR.1 SC
10.8
12.9
1PH8 with connector with fast release
5DF11
Power cable 4 x 2.5 GR.1.5 SC
10.0
12.1
1PH8 with connector with fast release
5CF12
Power cable 4 x 4 GR.1.5 SC
11.4
13.2
1PH8 with connector
without fast release
5CF13 Power cable 4 x 10 GR.3 20 19.4
x: 5 = MC500, 8 = MC800
