Siemens SINAMICS S120 Combi User Manual

Cabinet design and EMC
12.5 Connection system
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
283
12.5
Connection system
12.5.1
DRIVE-CLiQ signal cables
Note
Only MOTION
-CONNECT 500 and MOTION-CONNECT 800PLUS DRIVE-CLiQ cables are
permitted for the connection. The maximum cable length for MOTION
-CONNECT
500 cables
i
s 100 m, for MOTION-CONNECT 800PLUS cables 75 m.
The maximum permissible cable length for the use of DRIVE-CLiQ couplings is calculated as
follows:
ΣMC500 + 4/3 x ΣMC800PLUS + n
C
x 5 m ≤ 100 m
ΣMC500: Total length of all MC500 cable segments (fixed routing)
ΣMC800PLUS: Total length of all MC800PLUS cable segments (tow chain)
n
C
: Number of DRIVE-CLiQ couplings (max. 0 ... 3)
Table 12- 6 Comparison between MOTION-CONNECT 500 and MOTION-CONNECT 800PLUS DRIVE-CLiQ cables
DRIVE-CLiQ signal cable
MOTION-CONNECT 500
MOTION-CONNECT 800PLUS
Approvals
VDE
cURus or UR/CSA
UR-CSA File No.
1)
in conformance with RoHS
Yes
UL STYLE 2502/CSA-N.210.2-M90
Yes
Yes
Yes
UL STYLE 2502/CSA-N.210.2-M90
Yes
Yes
Rated voltage V
0
/V
in accordance with EN 50395
30 V 30 V
Test voltage, rms
500 V
500 V
Operating temperature at the surface
Permanently installed
Moveable
-20 ... +80 °C
0 ... 60 °C
-20 … +80 °C
-20 … +60 °C
Strain, max.
Permanently installed
Moveable
80 N/mm
2
30 N/mm
2
50 N/mm
2
20 N/mm
2
Smallest bending radius
Permanently installed
Moveable
35 mm
125 mm
35 mm
75 mm
Torsional stress
30°/m absolute
30°/m absolute
Bending operations
100000
10 million
Max. traversing speed
30 m/min
300 m/min
Max. acceleration
2 m/s
2
Up to 50 m/s
2
(3 m)
insulation material
CFC/silicone-free
CFC/halogen-free/silicon-free
