Siemens SINAMICS S120 Combi User Manual

Encoder system connection
10.3 Sensor Module External SME20
SINAMICS S120 Combi
254 Manual, 11/2017, 6SL3097-4AV00-0BP7
Installation
1. Place the drilling pattern on the mounting surface. Make sure that the contact surface is
bare, unpainted metal.
2. Drill two holes with Ø 5.3 or M5 threaded holes according to the drilling pattern.
3. Fix the Sensor Module to the mounting surface. The tightening torque is 6 Nm.
10.3.7
Technical data
Table 10- 17 Technical data
6SL3055-0AA00-5EA3
Unit
Value
Electronics power supply
Voltage
Current (without encoder system)
Current (with encoder system)
Power loss
V
DC
A
DC
A
DC
W
24 (20.4 … 28.8)
≤ 0.15
≤ 0.25
≤ 4
Encoder system power supply
Voltage
Current
V
DC
A
DC
5
0.35
Encoder frequency that can be evaluated
(f
encoder
)
kHz ≤ 500
PE/ground connection
At the housing with M4 / 1.8 Nm screw
Weight
kg
0.31
Degree of protection
IP67
