S120 Combi Power Modules
4.7 Installation
SINAMICS S120 Combi
94 Manual, 11/2017, 6SL3097-4AV00-0BP7
Holes to remove/tighten the screws on the air baffle plate of the S120 Combi
Figure 4-18 Installed reinforcement plates: View from the front and from the rear
Burns due to incorrect mounting of the reinforcement plates
If the reinforcing plates are incorrectly mounted, this can result in an excessively high heat
sink temperature and cause the S120 Combi Power Module to prematurely trip.
Contact with hot parts may cause you to suffer a burn injury.
• Follow the installation instructions when mounting the reinforcement plates.
