Siemens SINAMICS S120 Combi User Manual

System overview
2.2 System data
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
31
Climatic environmental conditions
Long-term storage Class 1K4 according to EN 60721-3-1, in product packaging
1)
Temperature: -25° C … +55° C
Transport Class 2K4 according to EN 60721-3-2, in transport packaging
2)
Temperature: -40 … +70° C
Operation Class 3K3 according to EN 60721-3-3 with increased ruggedness with respect
to relative humidity
Temperature: 0° C … +45° C without derating
> +45° C ... +55° C with reduction of the output current by 4.0% per ° C
Relative humidity: 5% … 95% without condensation (better than Class 3K3)
Oil mist, salt mist, ice formation, condensation, dripping water, spraying water,
splashing water and water jets are not permitted
Mechanical environmental conditions
Long-term storage
Class 1M2 according to EN 60721-3-1, in product packaging
1)
Transport
Class 2M3 according to EN 60721-3-2, in transport packaging
2)
Operation
Vibration test in operation
Shock test in operation
Class 3M1 according to EN 60721-3-3
In accordance with IEC 60068-2-6 Test Fc (sinusoidal)
• 10 ... 57 Hz: 0.075 mm deflection amplitude
• 57 ... 150 Hz: 1 g acceleration amplitude
• 10 frequency cycles per axis
In accordance with IEC 60068-2-27 Test Ea (half-sine)
• 5 g peak acceleration
• 30 ms duration
• 3 shocks in all three axes in both directions
Installation altitude
Operation 0 ... 1000 m above sea level without derating
> 1000 … 4000 m
• Reduction of the output current by 10% per 1000 meters, or
• Reduction in the ambient temperature by 5° C per 1000 meters
> 2000 … 4000 m
• Operation on line supply systems with grounded neutral point, or
• Operation on an isolating transformer with secondary grounded neutral
1)
Product packaging (storage packaging) is individual packaging for storage - and does not satisfy the requirements for
transport. As a consequence, product packaging is therefore not suitable for shipping.
2)
Transport packaging is either packaging that is directly suitable for transport - or secondary packaging, which together
with the product packaging, satisfies the requirements for transport.
Table 2- 4 Certificates
Declarations of Conformity
CE
Approvals
cURus
