4.4 Active Line Modules with external air cooling
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
191
External air cooling
6SL3131-
7TE21-6AA.
7TE23-6AA.
7TE25-5AA.
7TE25-5AA3 +
Active Inter-
face Module
Rated power
kW
16
36
55
55
Total power loss
(including electronics losses, see
Power loss tables (Page 756))
W 282.8 666 945.6 945.6
DC link capacitance
Active Line Module
Drive line-up, max.
μF
μF
705
20000
1410
20000
1880
20000
1880
20000
Power factor
cos φ
1
1
1
1
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and circuit
breakers (Page 51)
Rated short-circuit current
SCCR
3)
kA 65 65 65 65
Max. total cable length
4)
See Chapter Combination options, Line Modules with line reac-
tors and line filters (Page 135)
Sound pressure level
dB(A)
< 60
< 65
< 60
< 60
Cooling air requirement
m
3
/h
56
112
160
160
Max. permissible heat sink tempera-
ture
° C 85 90 88 88
Rated voltage for rated data 3 AC 380 V
Weight
kg
8.78
13.77
18.5
18.5
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
4)
Maximum total cable length = Σ motor cables, line feeder cable from line filter to the Line Module
Table 4- 23 Technical data for Active Line Modules with external air cooling, part 2
External air cooling
6SL3131-
7TE28-0AA.
7TE31-2AA.
Rated power
kW
80
120
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
80
106
131
120
145
175
Regenerative feedback
Continuous regenerative power
Peak regenerative power
kW
kW
80
131
120
175
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
ACrms
Hz
V
DC
3 AC 380 … 480 ±10 % (- 15 % < 1 min)
47 … 63 Hz
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
