Siemens SINAMICS S120 - Page 192

Line Modules Booksize
4.4 Active Line Modules with external air cooling
Booksize Power Units
192 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
External air cooling
6SL3131-
7TE28-0AA.
7TE31-2AA.
Rated power
kW
80
120
Input currents
Rated input current
at AC 400 V
Input current
at AC 380 V / AC 480 V
at AC 400 V; S6 duty (40 %)
at AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
122
128 / 102
161
200
182
192 / 152
220
267
DC link currents
Rated DC link current
at 600 V:
DC link current:
for 600 V DC; S6 duty (40 %)
for 600 V DC; peak current
A
DC
A
DC
A
DC
134
176
218
200
244
292
Current carrying capacity
DC link busbars
24 V busbars
A
DC
A
DC
200
20
200
20
Electronics current drawn
at 24 V DC
A
DC
1.4
1.8
Total power loss
(including electronics losses, see Power
loss tables (Page 756))
W 1383.6 2243.2
DC link capacitance
Active Line Module
Drive line-up, max.
μF
μF
2820
20000
3995
20000
Power factor
cos φ
1
1
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and circuit
breakers (Page 51)
Rated short-circuit current
SCCR
3)
kA 65 65
Max. total cable length
4)
See Chapter Combination options, Line Modules with line
reactors and line filters (Page 135)
Sound pressure level
dB(A)
< 73
< 73
Cooling air requirement
m
3
/h
520
520
Max. permissible heat sink temperature
73
83
Rated voltage for rated data 3 AC 380 V
Weight
kg
27.66
30.74
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
4)
Maximum total cable length = Σ motor cables, line feeder cable from line filter to the Line Module
