Remedy: Set a physical address with a value other than zero.
Note:
The alarm is r
eset as follows:
- Remove the cause of this alarm.
- Restart the function generator.
A02040 Function generator: Illegal value for o󹪜set
Messag
e class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The value for the o󹪜se
t is higher than t
he value for the upper limit or lower than the value for the lower limit.
Remedy: Adjust the o󹪜set value accor
dingly.
Note:
The alarm is reset as follows:
- Remove the cause of this alarm.
- Restart the function generator.
A02041 Function generator: Illegal value for bandwidth
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The bandwidth referred to the time slice clock cycle of the function generator has either been set too low or too high.
Depending on t
he time slice clock cy
cle, the bandwidth is de󹪝ned as follows:
Bandwidth_max = 1 / (2 x time slice clock cycle)
Bandwidth_min = Bandwidth_max / 100000
Example:
Assumption: Time slice clock cycle = 125 µs
--> Bandwidth_max = 1 / (2 x 125 µs) = 4000 Hz
--> Bandwidth_min = 4000 Hz / 100000 = 0.04 Hz
Remedy: Check the value for the bandwidth and adapt accordingly.
Note:
The alarm is r
eset as follows:
- Remove the cause of this alarm.
- Restart the function generator.
A02047 Function generator: Time slice clock cycle invalid
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The time slice clock cycle selected does not match any of the existing time slices.
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 493
