A02056 Trace: Recording cycle too short
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The selected recording clock cycle is shorter than the selected basic clock cycle 0.
Remedy: Increase the value for the trace cycle. The fastest cycle time can be read out using the commissioning tool.
A02057 Trace: Time slice clock cycle invalid
Message class: Error in the parameterization / con󹪝gur
ation / commis
sioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The time slice clock cycle selected does not match any of the existing time slices.
Remedy: Enter an existing time slice clock cycle. The fastest cycle time can be read out using the commissioning tool.
A02059 Trace: Time slice clock cycle for 2 x 8 recording channels not valid
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: The selected time slice clock cycle cannot be used for more than 4 recording channels.
Remedy: Enter the clock cycle of an existing time slice with a cycle time >= 4 ms or reduce the number of recording channels to 4
per tr
ace.
The fast
est cycle time can be read out using the commissioning tool.
A02060 Trace: Signal to be traced missing
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
Cause: - A signal to be traced was not speci󹪝ed.
- The speci󹪝ed signals ar
e not v
alid.
Remedy: - Specify the signal to be traced.
- Check whet
her the relevant signal can be traced.
A02062 Trace: Invalid trigger signal
Message class: Error in the parameterization / con󹪝guration / commissioning procedure (18)
Message value: -
Component: None
Response: NONE
Acknowledgment: NONE
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 495
