Siemens SINAMICS SIMOTICS S200 PROFINET - Page 499

Acknowledgment: NONE
Cause: A parameterization error was identi󹪝ed when s
tar
ting the variable message function.
Alarm value (r2124, interpret decimal):
yyxxxx dec: yy = index, xxxx = parameter
Remedy: Correct the parameter and restart.
Note:
The alarm is aut
omatically withdrawn when stopping, or when successfully starting the variable message function.
A02096 MTrace 0: cannot be saved
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: %1
Component: None
Response: NONE
Acknowledgment: NONE
Cause: It is not possible to save the measurement results of a multiple trace on the memory card (trace recorder 0).
A multiple tr
ace is not s
tarted or is canceled.
Alarm value (r2124, interpret decimal):
1: Memory card cannot be accessed.
- Card is not inserted or is blocked by a mounted USB drive.
3: Data save operation to slow.
- A second trace has been completed before the measurement results of the 󹪝rst trace were able to be saved.
- Writing the measurement result 󹪝les to the card is blocked by the parameter save.
4: Data save operation canceled.
- For instance, the 󹪝le required for the data save operation was not able to be found.
Remedy: - Insert or remove the memory card.
- Use a larger memor
y card.
- Con󹪝gure a longer trace time or use an endless trace.
- Avoid saving parameters while a multiple trace is running.
- Check whether other functions are presently accessing measurement result 󹪝les.
A02098 MTrace 1: cannot be saved
Message class: Error in the parameterization / con󹪝gur
ation / commis
sioning pr
ocedure (18)
Message value: %1
Component: None
Response: NONE
Acknowledgment: NONE
Cause: It is not possible to save the measurement results of a multiple trace on the memory card (trace recorder 1).
A multiple tr
ace is not s
tarted or is canceled.
Alarm value (r2124, interpret decimal):
1: Memory card cannot be accessed.
- Card is not inserted or is blocked by a mounted USB drive.
3: Data save operation to slow.
- A second trace has been completed before the measurement results of the 󹪝rst trace were able to be saved.
- Writing the measurement result 󹪝les to the card is blocked by the parameter save.
4: Data save operation canceled.
- For instance, the 󹪝le required for the data save operation was not able to be found.
Remedy: - Insert or remove the memory card.
- Use a larger memor
y card.
- Con󹪝gure a longer trace time or use an endless trace.
- Avoid saving parameters while a multiple trace is running.
- Check whether other functions are presently accessing measurement result 󹪝les.
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 497
