Remedy: For parallel connections, only Active Interface Modules (AIM) with identical EEPROM versions may be used.
F05069 Parallel connection: AIM 󹪝rmwar
e versions di󹪜erent
Message class: General drive fault (19)
Message value: Parameter: %1
Component: -
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: The 󹪝rm
ware ver
sions of the Active Interface Module (AIM) do not match.
Fault value (r0949, interpret decimal):
Parameter in which the 󹪝rst di󹪜erent version number was detected.
Remedy: For parallel connections, only Active Interface Modules (AIM) with identical 󹪝rmwar
e versions may be used.
F06310 Supply voltage (p0210) incorrectly parameterized
Message class: Network fault (2)
Message value: -
Component: None
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: For AC/AC drive units, the measured DC link voltage lies outside the tolerance range after precharging has been completed.
The f
ollowing applies f
or the tolerance range: 1.16 * p0210 < r0070 < 1.6 * p0210
Note:
The fault can only be acknowledged when the drive is switched o󹪜.
See also: p0210 (Device supply voltage)
Remedy: - Check the parameterized supply voltage and if required change (p0210).
- Check the line v
oltage.
See also: p0210 (Device supply voltage)
F07011 Drive: Motor overtemperature
Message class: Motor overload (8)
Message value: %1
Component: Motor
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: The calculated motor temperature is too high.
P
ossible causes:
- Mo
tor overloaded.
- Motor ambient temperature too high.
- Sensor wire breakage.
Fault value (r0949, interpret decimal):
200:
Motor temperature model 1 (I2t): temperature too high.
300:
Motor temperature model 3: after the monitoring time has expired, the temperature is still higher than the alarm threshold.
301:
Motor temperature model 3: temperature is too high, or the model has not been parameterized.
302:
Motor temperature model 3: Encoder temperature is not within the valid range.
400:
Additional motor overload protection: the load is too high.
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
502 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
