 13 Maintenance required Yes No 
 14 Maintenance urgently required Yes No 
 15 Fault gone/can be acknowledged Yes No 
Note
F
or bit 03 ... 00:
Bit 3, 2, 1, 0 = 0, 0, 0, 0 --> component no
t available.
Bit 3, 2, 1, 0 = 0, 0, 0, 1 --> run up, acyclic communications (LED = orange).
Bit 3, 2, 1, 0 = 0, 0, 1, 0 --> operating mode, cyclic communications (LED = green).
Bit 3, 2, 1, 0 = 0, 0, 1, 1 --> alarm (LED = green).
Bit 3, 2, 1, 0 = 0, 1, 0, 0 --> fault (LED = red).
Bit 3, 2, 1, 0 = 0, 1, 0, 1 --> detection via LED and operating mode (LED = green/orange).
Bit 3, 2, 1, 0 = 0, 1, 1, 0 --> detection via LED and alarm (LED = green/orange).
Bit 3, 2, 1, 0 = 0, 1, 1, 1 --> detection via LED and fault (LED = red/orange).
Bit 3, 2, 1, 0 = 1, 0, 0, 0 --> 󹪝rmware being downloaded (LED = green/red with 0.5 Hz).
Bit 3, 2, 1, 0 = 1, 0, 0, 1 --> 󹪝rmware download completed, wait for POWER ON (LED = green/red with 2.0 Hz).
For bits 12 ... 11:
These status bits are used for the classi󹪝cation of internal alarm classes and are intended for diagnostic purposes only
on certain automation systems with integrated SINAMICS functionality.
p0201[0] Power unit code number
 Data type: Unsigned16 Visible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Power unit
 Unit: -
 Min:
0
Max:
65535
Factory setting:
0
Description: Sets the actual code number of the power unit being used.
p0210 Device supply voltage
 Data type: Unsigned16 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Ready for operation
Parameter group: Power unit, Quick commissioning
 Unit: V
 Min:
1 [V]
Max:
63000 [V]
Factory setting:
400 [V]
Description: Sets the device supply voltage.
The voltag
e between two phases should be entered as the device supply voltage.
This setting is important for operating with voltages that are less than the voltage range for which the drive is designed.
Note
Setting rang
es for p0210 as a function of the rated power unit voltage:
U_rated = 230 V:
- p0210 = 200 ... 240 V
U_rated = 400 V:
- p0210 = 380 ... 480 V (wide voltage range, in addition to 200 ... 240 V)
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
