p0215 Braking resistor selection
 Data type: Integer16 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Dynamic braking, Quick commissioning
 Unit: -
 Min:
3
Max:
10
Factory setting:
10
Description: Sets the external braking resistor.
Value: 3: Third-party braking resistor (with monitoring)
 10: No monitoring (external braking resistor)
Dependency: See also: p0216, p0218, p0219
Note
p0215 = 3:
An e
xternally connected braking resistor is controlled and also thermally monitored per software.
Parameters p0216, p0218 and p0219[0] and p0219[1] must be set in order that the monitoring functions. Chopper
operation is not possible if the values are not set.
p0215 = 10:
The externally connected braking resistor is not monitored.
The internal braking resistor is monitored.
p0216 Braking resistance value
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Dynamic braking, Quick commissioning
 Unit: ohm
 Min:
0.0 [ohm]
Max:
1000.0 [ohm]
Factory setting:
0.0 [ohm]
Description: Sets the resistance value of a connected external braking resistor.
Dependency: The parameter is only relevant for p0215 = 2, 3.
p0218 Braking resistor maximum power duration
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Dynamic braking, Quick commissioning
 Unit: s
 Min:
0.00 [s]
Max:
2000.00 [s]
Factory setting:
0.00 [s]
Description: Sets the maximum duration when operating the braking resistor at its maximum power level.
Dependency: The parameter is only relevant for p0215 = 2, 3.
