r0479[0...2] Diagnostics encoder position actual value Gn_XIST1
 Data type: Integer32 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Motor encoder
Unit: -
Description: Display for the encoder position actual value Gn_XIST1 according to PROFIdrive for diagnostics.
The value is display
ed with sign.
Index: [0] = Motor encoder
[1] = Reserved
[2] = Reser
ved
p0488[0...2] Measuring probe 1 input terminal
 Data type: Integer16 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Measuring probe, Traversing blocks
 Unit: -
 Min:
0
Max:
210
Factory setting:
[0] 210
[1] 0
[2] 0
Description: Sets the input terminal to connect probe 1.
Value: 0: No measuring probe
 210: DI 0 (X130.1)
Index: [0] = Motor encoder
[1] = Reser
ved
[2] = Reserved
Dependency: See also: p0489, p0490
CAUTION
In order to prevent incorrect measurement values, these parameters may not be written during an active measurement.
Note
DI: Digital Input
Ref
er to the encoder interface for PROFIdrive.
If parameterization is rejected, check whether the terminal is already being used in p2517 or p2518.
p0489[0...2] Measuring probe 2 input terminal
 Data type: Integer16 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Measuring probe, Traversing blocks
 Unit: -
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 717
