 Min:
0
Max:
211
Factory setting:
[0] 211
[1] 0
[2] 0
Description: Sets the input terminal to connect probe 2.
Value: 0: No measuring probe
 211: DI 1 (X130.2)
Index: [0] = Motor encoder
[1] = Reser
ved
[2] = Reser
ved
Dependency: See also: p0488, p0490
CAUTION
In order to prevent incorrect measurement values, these parameters may not be written during an active measurement.
Note
DI: Digital Input
Ref
er to the encoder interface for PROFIdrive.
If parameterization is rejected, check whether the terminal is already being used in p2517 or p2518.
p0490.0...1 Invert measuring probe or equivalent zero mark
 Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Measuring probe
 Unit: -
 Min:
-
Max:
-
Factory setting:
0000 bin
Description: Setting to invert the digital input signals to connect a measuring probe or an equivalent zero mark.
Bit array: Bit Signal name 1 signal 0 signal 
 00 DI 0 (X130.1) Inverted Not inverted 
 01 DI 1 (X130.2) Inverted Not inverted 
Dependency: See also: p0488, p0489, p0494
Note
The t
erminal must be se
t as input.
When the measuring probe or the equivalent zero mark is inverted, this has no e󹪜ect on the status displays of the digital
inputs (r0721, r0722).
DI: Digital Input
p0494[0] Equivalent zero mark input terminal
 Data type: Integer16 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Motor encoder, Homing
 Unit: -
 Min:
0
Max:
211
Factory setting:
0
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
718 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
