Description: Setting the code number for the brake.
0 = No data
1 = Manual entry
> 1 = v
alid code number
For value = 0:
- Parameters listed under Dependent are set to a value of zero and are write protected.
- Parameters p1216, p1217 are set to a value of zero.
For value = 1:
- Write protection for the parameters listed under Dependent is withdrawn.
For value > 1:
- Parameters listed under Dependent are automatically pre-assigned and are write protected.
- Parameters p1216, p1217 are automatically appropriately pre-assigned.
Dependency: See also: p0550
Note
Only code numbers can be se
t that are permitted for the selected motor code (p0301).
p0613[0] Mot_temp_mod 1/3 ambient temperature
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Motor temperature
 Unit: °C
 Min:
-40 [°C]
Max:
100 [°C]
Factory setting:
20 [°C]
Description: If the thermal motor model is activated for permanent-magnet synchronous motors, then the parameter is
incorporated in t
he model calculation if a temperature sensor is not being used.
Dependency: See also: F07011, A07012
Note
If the
thermal motor model is activated for permanent-magnet synchronous motors, then the parameter is incorporated
in the model calculation if a temperature sensor is not being used.
r0721.0...3 CU digital inputs terminal actual value
 Data type: U
nsigned32 V
isible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Digital inputs
Unit: -
Description: Displays the actual value at the digital inputs.
This means that the actual in
put signal can be checked at terminal DI x prior to switching from the simulation mode
(p0795.x = 1) to the terminal mode (p0795.x = 0).
Bit array: Bit Signal name 1 signal 0 signal 
 00 DI 0 (X130.1) High Low 
 01 DI 1 (X130.2) High Low 
 02 DI 2 (X130.3) High Low 
 03 DI 3 (X130.4) High Low 
Note
DI: Digit
al Input
