r0722.0...3 Digital inputs status
 Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Digital inputs
Unit: -
Description: Display and signal source for the status of the digital inputs.
Bit array: Bit Signal name 1 signal 0 signal 
 00 DI 0 (X130.1) High Low 
 01 DI 1 (X130.2) High Low 
 02 DI 2 (X130.3) High Low 
 03 DI 3 (X130.4) High Low 
Dependency: See also: p0488, p0489
Note
DI: Digit
al Input
F
or bits 00, 01: DI 0 and DI 1 are fast digital inputs and can be used as measuring probe (p0488, p0489).
c0730 Signal for terminal DO 0
 Data type: U
nsigned8 V
isible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Relay outputs, Digital outputs
Unit: -
Description: Signal for terminal DO 0 (X130.11/12).
Note
DO: Digital Output
c0731 Signal for terminal DO 1
S200 PN Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Relay outputs, Digital outputs
Unit: -
Description: Signal for terminal DO 1 (X130.13/14).
Note
DO: Digital Output
r0747.0 Digital outputs status
S200 Basic PN Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Relay outputs, Digital outputs
Unit: -
Description: Displays the status of digital outputs.
Bit array: Bit Signal name 1 signal 0 signal 
 00 DO 0 (DO+: X130.11 / DO-: X130.12) High Low 
Note
DO: Digital Output
