r0747.0...1 Digital outputs status
S200 PN Data type: Unsigned32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Relay outputs, Digital outputs
Unit: -
Description: Displays the status of digital outputs.
Bit array: Bit Signal name 1 signal 0 signal
00 DO 0 (DO+: X130.11 / DO-: X130.12) High Low
01 DO 1 (DO+: X130.13 / DO-: X130.14) High Low
Note
DO: Digit
al Output
p0795.0...3 Digital inputs simulation mode
Data type: U
nsigned32 V
isible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Digital inputs
Unit: -
Min:
-
Max:
-
Factory setting:
0000 bin
Description: Sets the simulation mode for digital inputs.
Bit array: Bit Signal name 1 signal 0 signal
00 DI 0 (X130.1) Simulation Terminal eval
01 DI 1 (X130.2) Simulation Terminal eval
02 DI 2 (X130.3) Simulation Terminal eval
03 DI 3 (X130.4) Simulation Terminal eval
Dependency: The setpoint for the input signals is specied using p0796.
See also: p0796
Note
This par
amet
er is not saved when backing up data (p0977).
DI: Digital Input
p0796.0...3 Digital inputs simulation mode setpoint
Data type: Unsigned32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Digital inputs
Unit: -
Min:
-
Max:
-
Factory setting:
0000 bin
Description: Sets the setpoint for the input signals in the digital input simulation mode.
Bit array: Bit Signal name 1 signal 0 signal
00 DI 0 (X130.1) High Low
01 DI 1 (X130.2) High Low
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
722 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
