 02 DI 2 (X130.3) High Low 
 03 DI 3 (X130.4) High Low 
Dependency: The simulation of a digital input is selected using p0795.
See also: p0795
Note
This par
amet
er is not saved when backing up data (p0977).
DI: Digital Input
c0849[0] No Quick Stop / Quick Stop (OFF3)
 Data type: Unsigned8 Visible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Shutdown functions, Drive enable signals
Unit: -
Description: Second signal for command "No Quick Stop / Quick Stop (OFF3)"
The following signals ar
e AND'ed:
- c0848 "No Quick Stop / Quick Stop (OFF3) signal 1"
- c0849 "No Quick Stop / Quick Stop (OFF3) signal 2"
For the PROFIdrive pro󹪝le, the result of the AND logic operation corresponds to control word 1 bit 2 (STW1.2).
c0848 = 0 signal or c0849 = 0 signal
- OFF3 (braking along the OFF3 ramp (p1135), then pulse cancellation and switching on inhibited)
c0848 = 1 signal or c0849 = 1 signal
- No OFF3 (enable is possible)
CAUTION
When "master control from PC" is activated, then this binary signal sink is e󹪜ective.
Note
For driv
es with closed-loop torque control (activated using c1501), the following applies:
0 signal:
- No dedicated braking response, but pulse cancellation when standstill is detected (p1226, p1227).
r0898.0...14 Control word sequence control
 Data type: Unsigned16 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Control/status words
Unit: -
Description: Display and numerical signal source for the control word of the sequence control.
Bit array: Bit Signal name 1 signal 0 signal 
 00 ON/OFF1 Yes No 
 01 Operating condition / OFF2 Yes No 
 02 Operating condition / OFF3 Yes No 
 03 Enable operation Yes No 
 04 Enable ramp-function generator Yes No 
 05 Continue ramp-function generator Yes No 
 06 Enable speed setpoint Yes No 
 07 Command open brake Yes No 
 10 Master control by PLC Yes No 
 12 Enable speed controller Yes No 
 14 Command close brake Yes No 
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 723
