p1663[0] Current setpoint 󹪝lter 2 denominator natur
al frequency
 Data type: FloatingPoint32 Visible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: Hz
 Min:
0.5 [Hz]
Max:
16000.0 [Hz]
Factory setting:
1999.0 [Hz]
Description: Sets the denominator natural frequency for current setpoint 󹪝lter 2 (PT2, gener
al 󹪝lter).
Dependency: Current setpoint 󹪝lter 2 is activat
ed via p1656.1 and parameterized via p1662 ... p1666.
p1664[0] Current setpoint 󹪝lter 2 denominator dam
ping
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: -
 Min:
0.001
Max:
10.000
Factory setting:
0.700
Description: Sets the denominator damping for current setpoint 󹪝lter 2.
Dependency: Cur
rent setpoint 󹪝lter 2 is activat
ed via p1656.1 and parameterized via p1662 ... p1666.
p1665[0] Current setpoint 󹪝lter 2 numerat
or natural frequency
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: Hz
 Min:
0.5 [Hz]
Max:
16000.0 [Hz]
Factory setting:
1999.0 [Hz]
Description: Sets the numerator natural frequency for current setpoint 󹪝lter 2 (gener
al 󹪝lter).
Dependency: Current setpoint 󹪝lter 2 is activat
ed via p1656.1 and parameterized via p1662 ... p1666.
p1666[0] Current setpoint 󹪝lter 2 numerat
or damping
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: -
 Min:
0.000
Max:
10.000
Factory setting:
0.700
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 751
