r2139.0...15 Status word faults/alarms 1
 Data type: Unsigned16 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays status word 1 of faults and alarms.
Bit array: Bit Signal name 1 signal 0 signal 
 00 Being acknowledged Yes No 
 01 Acknowledgment required Yes No 
 03 Fault present Yes No 
 05 Safety message present Yes No 
 07 Alarm present Yes No 
 11 Alarm class bit 0 High Low 
 12 Alarm class bit 1 High Low 
 13 Maintenance required Yes No 
 14 Maintenance urgently required Yes No 
 15 Fault gone/can be acknowledged Yes No 
Note
F
or bit 03, 05, 07:
These bits are se
t if at least one fault/alarm or safety message occurs. The entry in the fault/alarm bu󹪜er or safety
message bu󹪜er is delayed. This is the reason that the fault/alarm bu󹪜er or safety message bu󹪜er should only be read if,
after "Fault active", "Alarm active" or "Safety message active" occurs, a change is also identi󹪝ed in the bu󹪜er (r0944,
r2121, r60044).
For bits 11, 12:
These status bits are used for the classi󹪝cation of internal alarm classes and are intended for diagnostic purposes only
on certain automation systems with integrated SINAMICS functionality.
r2145[0...63] Alarm time received in days
 Data type: Unsigned16 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays the system runtime in days when the alarm occurred.
Dependency: See also: r2114, r2122, r2123, r2124, r2125, r2134, r2146, r3123
NOTICE
The time comprises r2145 (days) and r2123 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
r2146[0...63] Alarm time cleared in days
 Data type: Unsigned16 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays the system runtime in days when the alarm was cleared.
Dependency: See also: r2114, r2122, r2123, r2124, r2125, r2134, r2145, r3123
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 765
