NOTICE
The time comprises r2146 (days) and r2125 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
p2149[0].16 Monitoring con󹪝guration
 Data type: U
nsigned32 Visible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages, Load torque monitoring
 Unit: -
 Min:
-
Max:
-
Factory setting:
0000 0000 0000 0001 0000 0000 0000
0000 bin
Description: Sets the con󹪝guration for mes
sages and monitoring functions.
Bit array: Bit Signal name 1 signal 0 signal 
 16 Line voltage failure detection Yes No 
Note
F
or bit 16:
When the bit is se
t, the line voltage failure detection function is activated
p2153[0] Speed actual value 󹪝lter time const
ant
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages
 Unit: ms
 Min:
0 [ms]
Max:
1000000 [ms]
Factory setting:
0 [ms]
Description: Sets the time constant of the PT1 element to smooth the speed / velocity actual value.
The smoot
hed actual speed/velocity is compared with the threshold values and is only used for messages and signals.
p2161[0] Speed threshold 3
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages
 Unit: rpm
 Min:
0.00 [rpm]
Max:
210000.00 [rpm]
Factory setting:
5.00 [rpm]
Description: Sets the speed threshold value for signal "|n_act| < speed threshold 3".
Dependency: See also: r2199
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
766 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
