p2162[0] Hysteresis speed n_act > n_max
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages
 Unit: rpm
 Min:
0.00 [rpm]
Max:
60000.00 [rpm]
Factory setting:
0.00 [rpm]
Description: Sets the hysteresis speed (bandwidth) for signal "n_act > n_max".
NOTICE
For p0322 = 0, the following applies: p2162 <= 0.1 * p0311
F
or p0322 > 0, t
he f
ollowing applies: p2162 <= 1.02 * p0322 - p1082
If one of the conditions is violated, p2162 is appropriately and automatically reduced when exiting the commissioning
mode.
Note
For a
negative speed limit, the hysteresis is e󹪜ective below the limit value and for a positive speed limit, above the limit
value.
If signi󹪝cant overshoot occurs in the maximum speed range (e.g. due to load shedding), you are advised to increase the
dynamic response of the speed controller (if possible). If this is insu󹪟cient, the hysteresis p2162 can only be increased
by more than 10% of the rated speed when the maximum speed (p0322) of the motor is su󹪟ciently greater than the
speed limit p1082.
p2175[0] Motor blocked speed threshold
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages
 Unit: rpm
 Min:
0.00 [rpm]
Max:
210000.00 [rpm]
Factory setting:
120.00 [rpm]
Description: Sets the speed threshold for message "Motor blocked".
Monitoring is deactiv
ated with p2175 = 0.
Dependency: See also: p2177
See also: F07900
Note
If the mot
or speed is less than the threshold value set in p2175 - and the motor is operated for longer than 200 ms at
the torque limit - then the motor is shut down and a fault is output.
p2177[0] Motor blocked delay time
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed messages
 Unit: s
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 767
