Min:
0.000 [s]
Max:
65.000 [s]
Factory setting:
1.000 [s]
Description: Sets the delay time for the message "Motor blocked".
Dependency: See also: p2175
See also: F07900
r2199.0...11 Status word monitoring 3
Data type: U
nsigned16 Visible in: Ext
ended display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Speed messages, Control/status words
Unit: -
Description: Displays the third status word of the monitoring functions.
Bit array: Bit Signal name 1 signal 0 signal
00 |n_act| < p2161 Yes No
01 f or n comparison value reached or exceeded Yes No
04 Speed setpoint - actual value deviation in tolerance t_on Yes No
05 Ramp-up/ramp-down completed Yes No
11 Torque utilization < torque threshold value 2 Yes No
Note
F
or bit 00:
The speed thr
eshold 3 is set in p2161.
For bit 01:
The comparison value is set in p2141. We recommend setting the hysteresis (p2142) for canceling the bit to a value
lower than that in p2141. Otherwise, the bit is not reset.
For bit 11:
The torque threshold value 2 is set in p2194.
p2496 LR dimension system physical length units
Data type: Integer16 V
isible in: Standard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Position control
Unit: -
Min:
0
Max:
8
Factory setting:
3
Description: Sets the physical length units.
Value: 0: LU (no dimension)
1: km
2: m
3: mm
4: µm
5: nm
6: in
7: ft
8: mi
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
768 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
