p2587 EPOS jog 1 traversing distance
S200 Basic PN (EPOS
Lastseite r
otierend),
S200 PN (EPOS
Lastseite rotierend)
Data type: FloatingPoint32 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Jog
 Unit: °
 Min:
0.0000 [°]
Max:
2.1474828e+09 [°]
Factory setting:
36.0000 [°]
Description: Sets the traversing distance for incremental jog 1.
Dependency: See also: p2585, c2589, c2591
Note
Incremental jog 1 is s
tarted with c2591 = 1 signal and c2589 = 0/1 signal.
With c2589 = 0 signal, incremental jogging is interrupted.
p2588 EPOS jog 2 traversing distance
 Data type: FloatingP
oint32 V
isible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Jog
 Unit: mm
 Min:
0.0000 [mm]
Max:
2.1474828e+09 [mm]
Factory setting:
1.0000 [mm]
Description: Sets the traversing distance for incremental jog 2.
Dependency: See also: p2586, c2590, c2591
Note
Incremental jog 2 is s
tarted with c2591 = 1 signal and c2590 = 0/1 signal.
Incremental jogging is interrupted with c2590 = 0 signal.
p2588 EPOS jog 2 traversing distance
S200 Basic PN (EPOS
Lastseite r
otierend),
S200 PN (EPOS
Lastseite rotierend)
Data type: FloatingPoint32 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Jog
 Unit: °
 Min:
0.0000 [°]
Max:
2.1474828e+09 [°]
Factory setting:
36.0000 [°]
Description: Sets the traversing distance for incremental jog 2.
Dependency: See also: p2586, c2590, c2591
Note
Incremental jog 2 is started with c2591 = 1 signal and c2590 = 0/1 signal.
Incremental jogging is interrupted with c2590 = 0 signal.
