Description: Signal to start "Active homing" or "Passive homing".
0/1 signal edge: Homing is st
arted.
1/0 signal edge: Homing is interrupted.
Dependency: See also: c2597, c2598, p2599, r2684
NOTICE
The parameter may be protected as a result of r0922 and cannot be changed.
Note
A
ctiv
e homing (c2597 = 0 signal):
A
ctive homing can only be activated (0/1 edge) after traversing motion that is being processed has been completed.
With the start, where relevant, the state signal "home position set" (r2684.11) is reset.
Passive homing (c2597 = 1 signal):
With the start, the state signal "home position set" (r2684.11) is not reset.
c2596 EPOS set home position
 Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Homing
Unit: -
Description: Signal for "Set home position".
Dependency: See also: c2598, p2599, r2684
NOTICE
The parameter may be protected as a result of r0922 and cannot be changed.
Note
Home position setting is e󹪜ective
in the following operating states:
- In the basic state.
- For FIXED STOP with progress condition END (corresponds to the initial state).
- For traversing block interrupted via c2640 = 0 signal (intermediate stop).
- For EPOS not enabled and position actual value valid
c2597 EPOS homing type selection
 Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Homing
Unit: -
Description: Signal to select homing type.
1 signal: Passiv
e homing
0 signal: Active homing
Dependency: See also: c2595
Note
Homing is activated as f
ollows:
- Select homing type (c2597)
- Start homing (c2595 = 0/1 signal edge)
Appendix
A.3Parameters
