c2628 EPOS traversing block selection bit 3
 Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Traversing blocks
Unit: -
Description: Signal to select the traversing block, bit 3.
Dependency: Parameters c2625, c2626, c2627, c2628 and c2629 are used to select one of the maximum 64 traversing blocks.
See also: c2625, c2626, c2627, c2629
c2629 EPOS traversing block selection bit 4
 Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Traversing blocks
Unit: -
Description: Signal to select the traversing block, bit 4.
Dependency: Parameters c2625, c2626, c2627, c2628 and c2629 are used to select one of the maximum 64 traversing blocks.
See also: c2625, c2626, c2627, c2628
c2631 EPOS activate traversing task (0 -> 1)
 Data type: Unsigned8 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Traversing blocks
Unit: -
Description: Signal for "Activate traversing task".
c2631 = 0/1 signal
The trav
ersing task, selected using c2625 ... c2629, is started.
Dependency: See also: c2625, c2626, c2627, c2628, c2629, c2640, c2641
NOTICE
The parameter may be protected as a result of r0922 and cannot be changed.
Note
To st
art a traversing block, the axis must be referenced (r2684.11 = 1).
The status signal r2684.12 = 0/1 signal is used for acknowledgment.
A traversing task can be in󹪞uenced using the following signals:
- Intermediate stop via c2640.
- Reject traversing task via c2641.
p2632 EPOS external block change evaluation
 Data type: Integer16 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Ready for operation
Parameter group: Traversing blocks
 Unit: -
 Min:
0
Max:
1
Factory setting:
0
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
816 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
