p4422.0 PTO con󹪝guration
S200 PN Data type: U
nsigned16 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Pulse encoder emulation
 Unit: -
 Min:
-
Max:
-
Factory setting:
0000 bin
Description: Settings for Pulse Train Output (PTO).
Bit array: Bit Signal name 1 signal 0 signal 
 00 PTO position actual value Inverted Not inverted 
Dependency: See also: c4420
p4426 PTO zero mark o󹪜se
t
S200 PN Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Pulse encoder emulation
 Unit: -
 Min:
0
Max:
16777215
Factory setting:
0
Description: Sets a zero mark o󹪜set t
o shift the zero mark within one mechanical revolution.
Example:
p0408 = 2048 (encoder pulses)
p4426 = 512 (zero mark o󹪜set in pulses)
--> Positive direction: The zero mark is output o󹪜set by 512 pulses.
--> Negative direction: The zero mark is output o󹪜set by 1536 pulses.
Dependency: See also: p0408
Note
The setting for t
he zero mark o󹪜set (p4426) must be less than the encoder pulse number (p4408).
r4479 PTO diagnostics position actual value
 Data type: Integer32 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Pulse encoder emulation
Unit: -
Description: Display and numerical signal source for the PTO position actual value.
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 839
