6. Assemble the shielding B.
DEFG
Make sure that the installed shielding B is level. If it tilts upward, adjust as follows.
7. Insert the connector into the cable crimp slot in the crimping tool and crimp the cable shield.
8. Install the housing.
DEF
GHI
0DNHVXUHWKDWWKHFRYHUV
ODW
FKLQWRSODFH
Appendix
A.4î™ Assembling cables
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 883
