Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
375
Table 3-7 Jumper setting for the Contact Type of the relay for BO13
Table 3-8 Jumper setting of Control Voltages of binary inputs BI8 to BI15 on input/output board
C– I/O–1 in the 7UM622
1)
Factory settings for devices with rated power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 250 VDC and 115/230 VAC
3)
Use only with control voltages 220 to 250 VDC
Jumpers X71, X72 and X73 on the input/output module C-I/O-1 are used to set the bus address and must not
be changed. The following table lists the jumper presettings.
Mounting locations of modules are shown in Figures 3-1 to 3-2.
Table 3-9 Jumper setting of the Bus Address of the input/output board C-I/O-1 for 7UM622
Jumper Open in quiescent state (NO) Closed in quiescent state (NC) Presetting
X40 1-2 2-3 1-2
Binary inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
176 V Threshold
3)
BI8 X21/X22 L M H
BI9 X23/X24 L M H
BI10 X25/X26 L M H
BI11 X27/X28 L M H
BI12 X29/X30 L M H
BI13 X31/X32 L M H
BI14 X33/X34 L M H
BI15 X35/X36 L M H
Jumper Presetting
X71 L
X72 H
X73 H
