Section 03 ENGINE

Sub-Section 08 (REWIND STARTER)

03-08-2

503 Skandic 500 and Formula SL

A21C08S

10 N•m

(89 lbf•in)

Molykote G-n

Paste or

Equivalent

Silicone

Compound

Grease

Silicone

Compound

Grease

8 N•m

(71 lbf•in)

15

6

7

5

4 1

3

8

9

10

12

11

FLAT RATE

PARTS
