Section 05 ELECTRICAL
Sub-Section 07 (TESTING PROCEDURE)
05-07-15
INSPECTION OF AC CIRCUIT ISOLATION
All Electric Start Models
If AC circuit is not isolated from frame, headlamp
beam will weaken.
INSPECTION
Disconnect regulator/rectifier.
Connect one digital ohmmeter probe (needle
ohmmeter will not offer enough precision) to
frame and other probe to one of 2 yellow magneto
wires.
Measured resistance must be infinite. If such is
not the case, it means there is a connection be-
tween AC circuit and DC circuit.
Disconnect one accessory at the time to identify
the faulty circuit.
