Ski-Doo TOURING E LT 1997 - Torque Reaction Suspension

Section 06 REAR SUSPENSION
Sub-Section 02 (TORQUE REACTION SUSPENSION)
06-02-1
TORQUE REACTION SUSPENSION 2
Tundra II LT
A05F0HS
24 N•m
(18 lbf•ft)
19 N•m
(168 lbf•in)
1
2
3
4
5
48 N•m
(35 lbf•ft)
24 N•m
(18 lbf•ft)
6
48 N•m
(35 lbf•ft)
11 N•m
(97 lbf•in)
9
10
7
8
7
8
Loctite
271
24 N•m
(18 lbf•ft)
Loctite
271
Loctite
271
19 N•m
(168 lbf•in)
FLAT RATE
PARTS
