Section 05 ELECTRICAL
Sub-Section 02 (WIRING DIAGRAMS)
05-02-1
WIRING DIAGRAMS 2
hal. = halogen
CHART CODES
Wiring Color Code
The first color of a wire is the main color, second
color is the stripe.
Example: YL/BK is a YELLOW wire with a BLACK
stripe.
MODEL
WIRING
DIAGRAM
PAGE
HEADLIGHT
(watt)
TAILLIGHT
(watt)
ELECTRICAL
SYSTEM
OUTPUT
(watt)
Tundra II LT Annex 1 60/55 hal. 8/27 160
Formula S / SL, Skandic 380 / 500 Annex 2 60/55 hal. 8/27 240
Touring E / E LT / LE / SLE Annex 3 60/55 hal. 8/27 240
COLOR CODE
BK – BLACK
WH– WHITE
RD – RED
BL – BLUE
YL – YELLOW
GN – GREEN
GY – GREY
VI – VIOLET
OR – ORANGE
BR – BROWN
