Section 05 ELECTRICAL
Sub-Section 07 (TESTING PROCEDURE)
05-07-8
∞ : Infinity (extremely large number)
PART NAME WIRE COLOR* RESISTANCE OHM REMARKS
MAGNETO
Ignition generator
coil
BK with BK
/
RD
40 - 76
No display change
means open circuit.
Lighting generator
coil
YL with YL
/
BK
0.05 - 0.6
IGNITION
COIL
Primary winding
BK with WH
/
BL
0.11 - 0.21
(applicable to 277
engine type only)
0.34 - 0.62
(applicable to 503
Alpine II engine only)
Secondary winding
(spark plug
cap removed)
BR with high
tension wire
(applicable to 277
engine type only)
4.9 - 7.5 K
(4900 - 7500)
Display showing
zero (0) means
short circuit.
End of each high
tension wire
9 - 15 K
(9000 - 15000)
Insulation
WH
/
BL with core
∞Ω
WH
/
BL with high
tension wire
SPARK PLUG
CAP
Spark plug cap
— 4.5 - 5.5 K
*
COLOR CODE
BK – BLACK
WH – WHITE
RD – RED
BL – BLUE
YL – YELLOW
GN – GREEN
GY – GREY
VI – VIOLET
OR – ORANGE
BR – BROWN
