Ski-Doo TOURING E LT 1997 - Page 280

Section 09 TECHNICAL DATA
Sub-Section 03 (VEHICLES)
09-03-2
VEHICLE MODEL TOURING LE SKANDIC 380 TOURING SLE,
SKANDIC 500
FORMULA SL
ENGINE TYPE 443 377 503 503
Chain Drive Ratio 21/44 21/44 21/44 22/44
Chain Pitch in 3/8 3/8 3/8 3/8
Type / Links Qty / Plates Qty Silent / 72 / 11 Silent / 72 / 11 Silent / 72 / 11 Silent / 72 / 11
Drive Pulley Type of Drive Pulley TRA Bombardier Lite TRAC TRAC
Ramp Identification 227 ➃ N.A. 284 ➃ 284 ➃
Calibration Screw Position or
Calibration Disc Quantity ➄
41W4 3
Spring Color Yellow / Violet Yellow / Green Red / Yellow Blue / Yellow
Spring Length ± 1.5 mm
(± 0.060 in)
88.4
(3.48)
82
(3.23)
87.9
(3.46)
115.1
(4.53)
Clutch Engagement ± 200 RPM 3100 2900 3000 3600
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (± 1.5 lb)
degree
4.8 (10.6)
44°
4.8 (10.6)
44°
4.8 (10.6)
44°
4.8 (10.6)
44°
Pulley Distance Z (+0, –1) mm
((+0, –1/32) in)
16.5 (21/32) 25.5 (1) 16.5 (21/32) 16.5 (21/32)
Offset X ± 0.4 mm
(± 1/64 in)
35.0 (1-3/8) 33.4 (1-5/16) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN.
MAX.
+ 1 (+ 0.039)
+ 2 (+ 0.079)
+ 0.5 (+ 0.020)
+ 1.5 (+ 0.059)
+ 1 (+ 0.039)
+ 2 (+ 0.079)
+ 1 (+ 0.039)
+ 2 (+ 0.079)
Drive Belt Part Number (P / N) 415 0606 00 415 0606 00 415 0606 00 415 0606 00
Drive Belt Width (new) ➀ mm
(in)
34.7
(1-3/8)
34.7
(1-3/8)
34.7
(1-3/8)
34.7
(1-3/8)
Drive Belt Adjustment Deflection ± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg
(lbf)
11.3
(25)
11.3
(25)
11.3
(25)
11.3
(25)
Track Width cm
(in)
38.1
(15)
38.1
(15)
38.1
(15)
38.1
(15)
Length cm
(in)
345
(136)
345
(136)
345
(136)
307
(121)
Adjustment Deflection mm
(in)
40 – 55
(1-9/16 – 2-5/32)
40 – 55
(1-9/16 – 2-5/32)
40 – 55
(1-9/16 – 2-5/32)
40 – 55
(1-9/16 – 2-5/32)
Force ➂ kg
(lbf)
7.3
(16)
7.3
(16)
7.3
(16)
7.3
(16)
Suspension Type Track Slide Slide Slide Slide
Ski DSA DSA DSA DSA
Length cm
(in)
292 (115)
294
(115.7)
Touring : 292 (115)
Skandic : 294 (115.7)
272.5
(107.3)
Width cm
(in)
115.6 (45.5)
108
(42.5)
Touring : 120.7 (47.5)
Skandic : 108 (42.5)
120.7
(47.5)
Height cm
(in)
122 (48.0)
122
(48.0)
122
(48.0)
112
(44.1)
Ski Stance cm
(in)
101.6 (40)
94
(37)
Touring : 106.7 (42)
Skandic : 94 (37)
106.7
(42)
Mass (dry) kg
(lb)
208 (457)
214
(471)
Touring : 224 (493)
Skandic : 221 (486)
202
(445)
Ground Contact Area
cm
2
(in
2
)
7227 (1120)
7227
(1120)
7227
(1120)
6503
(1008)
Ground Contact Pressure kPa
(PSI)
2.82 (.409)
2.90
(.421)
Touring : 3.04 (.441)
Skandic : 3.06 (.435)
3.05
(.442)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Polyethylene Polyethylene Polyethylene Polyethylene
Cab Material RRIM
Polyurethane
RRIM
Polyurethane
RRIM
Polyurethane
RRIM
Polyurethane
Battery V
(A•h)
12
(22)
N.A.
Touring : 12 (22)
Skandic : N.A.
N.A.
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Bulb W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Bulb W N.A. N.A. N.A. N.A.
Fuse Starter Solenoid A 30 N.A. Touring : 30 Skandic : N.A. N.A.
Tachometer A N.A N.A. N.A. N.A.
Fuel Tank L
(U.S. gal)
40
(10.6)
40
(10.6)
40
(10.6)
40
(10.6)
Chaincase / Gearbox mL
(U.S. oz)
250
(8.5)
250
(8.5)
250
(8.5)
250
(8.5)
Cooling System L
(U.S. oz)
N.A. N.A. N.A. N.A.
Injection Oil Reservoir L
(U.S. oz)
2.55
(86)
2.55
(86)
2.55
(86)
2.55
(86)
