Section 05 ELECTRICAL
Sub-Section 02 (WIRING DIAGRAMS)
05-02-2
Following table shows wire colors related to electrical circuits.
WIRE COLORS ELECTRICAL CIRCUIT ADDITIONAL INFORMATION
BLACK/YELLOW ENGINE SHUT OFF
– Key switch
– Tether cord switch
– Emergency switch
Must be grounded to stop engine.
BLACK (small) Ground for shut off
BLACK (Big) Ground for starter (
−
)
YELLOW
YELLOW/BLACK
12 volts (A.C.) If shorted, magneto stops producing electricity.
RED 12 volts (D.C.) (
+
)
For starter motor
RED/GREEN 12 volts (D.C.) (
+
)
For starter solenoid
RED/BLUE 12 volts (D.C.) (
+
)
Rectifier output
GREY 12 volts (A.C.)
High beam
Current returns by YELLOW/BLACK wire
connected to headlamp.
VIOLET/GREY 12 volts (A.C.)
Low beam
WHITE 12 volts (A.C.)
Brake light
Current returns by YELLOW/BLACK wire
connected to taillight.
WHITE/RED 12 volts (A.C.)
Low oil level
Current returns by YELLOW/BLACK wire
connected to oil level sensor.
BLUE 12 volts (A.C.)
Fuel level indicator
Current returns by YELLOW wire connected
to fuel level sensor.
ORANGE 12 volts (A.C.)
Heated grips (max.)
Current returns by YELLOW/BLACK wire
connected to heating elements.
ORANGE/VIOLET 12 volts (A.C.)
Heated grips (min.)
BROWN 12 volts (A.C.)
Heated throttle lever (max.)
BROWN/YELLOW 12 volts (A.C.)
Heated throttle lever (min.)
GREEN 12 volts (A.C.)
Temperature gauge
Current returns by YELLOW wire connected
to sensor.
VIOLET 12 volts (A.C.)
Engine overheating light.
