09-03-1
Section 09 TECHNICAL DATA
Sub-Section 03 (VEHICLES)
VEHICLE MODEL MX Z 440 F MX Z 440 MX Z 583 MX Z 670
ENGINE TYPE 443 454 583 670
Chain Drive Ratio 22/44 23/44 25/44 26/44
Chain
Pitch in 3/8 3/8 3/8 3/8
Type/Links Qty/Plates Qty Silent/72/11 Silent 72 – 13 Silent 74 – 13 Silent 74 – 13
Drive Pulley
Type of Drive Pulley TRA TRAC TRAC TRAC
Ramp Identification 289 ➄ 283 ➄ 286 ➄ 286 ➅
Calibration Screw Position or
Calibration Disc Quantity ➄
3333
Spring Color Blue/Green Pink/White Green/Blue Violet/Yellow
Spring Length
± 1.5 mm
(± 0.060 in)
105.7
(4.16)
124.5
(4.9)
147.4
(5.80)
157.9
(6.22)
Clutch Engagement ± 200 RPM 3800 4400 4400 3800
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
6.1 (13.4)
47°
7.0 (15.4)
44°
7.0 (15.4)
50°
5.4 – 6.8 (11.9 – 15.0)
50°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
+ 1 (+ 0.039)
+ 2 (+ 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 414 0606 00 414 8607 00 414 8607 00 414 9182 00
Drive Belt Width (new) ➀ mm (in) 34.7 (1-3/8) 34.9 (1-3/8) 34.9 (1-3/8) 35.2 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0)
Length cm (in) 307 (121) 307 (121) 307 (121) 307 (121)
Adjustment
Deflection
mm
(in)
40 – 55
(1-9/16 – 2-5/32)
40 – 55
(1-9/16 – 2-5/32)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC10 Sport SC10 XC SC10 XC SC10 XC
Ski DSA DSA DSA DSA
Length cm (in) 272.5 (107.3) 272.5 (107.3) 272.5 (107.3) 272.5 (107.3)
Width cm (in) 114.3 (45.0) 116.9 (46.0) 116.9 (46.0) 117.2 (46.1)
Height cm (in) 108 (42.5) 108 (42.5) 108 (42.5) 108 (42.5)
Ski Stance cm (in) 101.6 (40) 104.5 (41.0) 104 (41.0) 104.5 (41.0)
Mass (dry) kg (lb) 201 (442) 220 (485) 228 (502) 228 (502)
Ground Contact Area
cm
2
(in
2
)
6629 (1028) 6629 (1028) 6629 (1028) 6629 (1028)
Ground Contact Pressure kPa (PSI) 2.97 (.437) 3.26 (.473) 3.37 (.489) 3.37 (.489)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Polyethylene Impact Copolymer Impact Copolymer Impact Copolymer
Cab Material RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane
Battery V (A•h) N.A. N.A. N.A. N.A.
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Buld W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Buld W N.A. N.A. N.A. N.A.
Fuse
Starter Solenoid A N.A. N.A. N.A. N.A.
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 37 (9.8) 37.0 (9.8) 37.0 (9.8) 37.0 (9.8)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 250 (8.5) 250 (8.5)
Cooling System L (U.S. oz) N.A. 4.7 (159) 4.7 (159) 4.7 (159)
Injection Oil Reservoir L (U.S. oz) 2.55 (86) 2.8 (95) 2.8 (95) 2.8 (95)
