Section 02 TROUBLESHOOTING
Sub-Section 05 (ELECTRICAL SYSTEM)
02-05-9
SYMPTOM BRAKE LIGHT REMAINS ON
CONDITION NORMAL USE
Test/Inspection 1. Check if bulb is properly installed.
a.Bulb is not installed correctly (contact elements are reversed).
Install bulb correctly.
2. Check brake switch.
a.Switch contact remains closed.
Adjust brake cable or brake switch.
SYMPTOM REAR LIGHT BULB FLASHES
CONDITION NORMAL USE
Test/Inspection 1. Check bulb tightness in housing.
a.Looseness at bulb contact elements.
Install bulb correctly.
2. Check if rear light is properly connected.
a.Connector housing is partially connected.
Install connector housing properly.
3. Check continuity of wires.
a.Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
SYMPTOM TACHOMETER DOES NOT WORK
CONDITION NORMAL USE
Test/Inspection 1. Check continuity of wires.
a.Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
