Section 08 BODY/FRAME
Sub-Section 03 (FRAME)
08-03-2
Grinding Procedure
Rear Cap
Grind rivet heads from top of rear cap and under-
neath for side retaining rivets.
1. Rivets heads ground
2. Rivets to be ground from underneath
To remove rivet, strike with a punch from rivet
head side.
Make a chamfer from underneath on all 4 corner
holes.
-
CAUTION
High speed drilling will cause excessive heat
which may destroy the cutting edge of the
bit, therefore avoid using pneumatic drills.
A06H0XA
1
2
