Section 09 TECHNICAL DATA
Sub-Section 03 (VEHICLES)
09-03-1
VEHICLE MODEL FORMULA III FORMULA III LT MACH 1 MACH Z
ENGINE TYPE 599 599 699 809
Chain Drive Ratio 25/44 23/44 26/44 26/44
Chain
Pitch in 3/8 3/8 3/8 3/8
Type/Links Qty/Plates Qty Silent/74/13 Silent/72/13 Silent/74/13 Silent/74/13
Drive Pulley
Type of Drive Pulley TRA TRA TRAC TRAC
Ramp Identification 281 ➅ 281 ➅ 286 ➅ 286 ➅
Calibration Screw Position or
Calibration Disc Quantity
4443
Spring Color Pink/White Pink/White Pink/White Green/Blue
Spring Length
± 1.5 mm
(± 0.060 in)
124.5
(4.90)
124.5
(4.90)
124.5
(4.90)
147.4
(5.80)
Clutch Engagement ± 200 RPM 4500 4500 4500 4100
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
7.0 (15.4)
50°
7.0 (15.4)
50°
7.0 (15.4)
47° – 50°
7.0 (15.4)
47° – 50°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 415 0603 00 415 0603 00 415 0603 00 415 0603 00
Drive Belt Width (new) ➀ mm (in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15) 38.1 (15) 38.1 (15.0) 38.1 (15.0)
Length cm (in) 307 (121) 345.5 (136) 307 (121) 307 (121)
Adjustment
Deflection
mm
(in)
35 – 40
(1-3/8 – 1-9/16)
35 – 40
(1-3/8 – 1-9/16)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC10 HP SC10 HP SC10 HP SC10 HP
Ski DSA DSA DSA DSA
Length cm (in) 272.0 (107.1) 291.0 (114.6) 272.0 (107.1) 272.5 (107.3)
Width cm (in) 115.9 (45.6) 118.2 (46.5) 115.9 (45.6) 115.9 (45.6)
Height cm (in) 108 (42.5) 108 (42.5) 108 (42.5) 108 (42.5)
Ski Stance cm (in) 104.2 (41) 104.2 (41) 104.2 (41) 104.2 (41)
Mass (dry) kg (lb) 249 (548) 252 (554) 251 (552) 258 (568)
Ground Contact Area
cm
2
(in
2
)
6103 (946) 7549 (1170) 6103 (946) 6103 (946)
Ground Contact Pressure kPa (PSI) 4.00 (.580) 3.27 (.474) 4.03 (.584) 4.15 (.602)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Impact Copolymer Impact Copolymer Impact Copolymer Impact Copolymer
Hood Material RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane
Battery V (A•h) N.A. N.A. N.A. N.A.
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Bulb W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Bulb W 3/3 3/3 3/3 3/3
Fuse
Starter Solenoid A N.A. N.A. N.A. N.A.
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 42 (11.1) 42 (11.1) 42 (11.1) 42 (11.1)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 250 (8.5) 250 (8.5)
Cooling System ➃ L (U.S. oz) 5.0 (169) 5.1 (172) 5.0 (169) 5.0 (169)
Injection Oil Reservoir L (U.S. oz) 4.1 (139) 4.1 (139) 4.1 (139) 4.1 (139)
