04-3

Section 04 DESS SYSTEM

1. 6-01 housing

Switch Wire Continuity Check

Check continuity (null resistance) between switch

center terminal and WHITE/GRAY wire (6-01A).

Check continuity (null resistance) between switch

side ring and BLACK/GREEN wire connector (6-

01B).

A06E2NA
