Ski-Doo TOURING E LT 1997 - Page 923

SHOP MANUAL SUPPLEMENT
MX Zx 440 LC
PAGE 18 OF 18
VEHICLE MODEL MX Zx 440 LC
ENGINE TYPE 454
Chain Drive Ratio 23/43
Chain
Pitch in 3/8
Type/Links Qty/Plates Qty Silent 72 – 13
Drive Pulley
Type of Drive Pulley TRAC
Ramp Identification 285 ➄
Calibration Screw Position or
Calibration Disc Quantity ➄
3
Spring Color Pink/Pink
Spring Length
± 1.5 mm
(± 0.060 in)
137.2
(5.4)
Clutch Engagement ± 200 RPM 4900
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
7.0 (15.4)
40° – 44°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 414 8607 00
Drive Belt Width (new) ➀ mm (in) 34.9 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25)
Track
Width cm (in) 38.1 (15.0)
Length cm (in) 307 (121)
Adjustment
Deflection
mm
(in)
30 – 35
(1-3/16 – 1-3/8)
Force ➂ kg (lbf) 7.3 (16)
Suspension Type
Track SC10 XC
Ski DSA
Length cm (in) 272.5 (107.3)
Width cm (in) 114.9 (45.3)
Height cm (in) 108 (42.5)
Ski Stance cm (in) 101.6 (40.0)
Mass (dry) kg (lb) 210 (462)
Ground Contact Area
cm
2
(in
2
)
6745 (1045)
Ground Contact Pressure kPa (PSI) 3.05 (0.442)
Frame Material Aluminum
Bottom Pan Material Impact Copolymer
Cab Material RRIM Polyurethane
Battery V (A•h) N.A.
Headlight WH4 60/55
Taillight and Stoplight W8/27
Tachometer and Speedometer Bulb W2 x 3
Fuel and Temperature Gauge Bulb WN.A.
Fuse
Starter Solenoid A N.A.
Tachometer A N.A.
Fuel Tank L (U.S. gal) 37.0 (9.8)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5)
Cooling System L (U.S. oz) 3.5 (118.4)
Rotary Valve Reservoir mL (U.S. oz) 50 (1.7)
